Moving polishing head aluminum polishing machine
Moving polishing head aluminum polishing machine with a fixed worktable
Remove the die line, scratch, surface defects
Save the space, save the cost and remote control the operation
Aluminium profile polishing machine technical parameter, Fixed worktable, moving polishing head
Aluminum polishing machine can remove such surface defects as naturally oxidized film, extruded lines, die line, scratch, marks, defects etc. to get a bright mirror effect on the surface of aluminum profile.
The aluminum profile will be soft color, high grade and elegant appearance after mechanical polishing treatment and various chemical treatments, which is the trend of development of aluminum profile application.
Working principle of aluminium profile polishing machine workbench is fixed and aluminum profile put on workbench; the polishing head moves back and forth, make the workpieces polished by the polishing wheels drove through the rotation of the motor; polishing wax is used on the surface of the polishing wheels as a polishing media.
Moving head polishing machine
Technical data of moving polishing head aluminum polishing machine
Main constitution: Main body, worktable, rail, dust collector, switch box
Technical data of aluminum profile polishing machine
Overall size: W 2000×L8000×H 2500mm
Effective processing size: W 600×L6000×H 250mm
Total rail length: 9000mm
Polishing wheel motor: 30kw
The polishing speed is 3-15m/min.
Machine polishing head driving motor: 2.2kw, gearbox speed control
Machine polishing head lifting motor 1.1kw gearbox speed control
Total power: 60kw
Aluminum polishing machine explains the excellent, high grade and high-quality surface processing technology, so that make the most aluminum extruders feel the convenience and efficiency of high-tech, most aluminum customers taste the charm of aluminum profiles.
Contact us now to obtain a reliable no-obligation quote on your aluminum profile polishing machine.
